| Display | |
| Model | DHI-LM27-E431A |
| LCD Technology | IPS |
| Backlight | ELED |
| Screen Size | 27 inch |
| Aspect Ratio | 16:9 |
| Viewing Size | 596.74 (H) × 335.66 (V) mm |
| Screen-to-Body Ratio | ≥90% |
| Viewing Angle | 178° (H)/178° (V) |
| Display Mode | Horizontal |
| Pixel Pitch | 0.1554 mm × 0.1554 mm (0.0061″ × 0.0061″) |
| Pixels Per Inch | 163.18 |
| Resolution | 3840 (H) × 2160 (V) |
| Refresh Rate | 320 Hz (at FHD resolution) |
| Display Color | 1.07B (8 bits + FRC) |
| Color Gamut | 98% DCI-P3 |
| Color Accuracy | ΔE<2 |
| Brightness | 300 cd/m² (typ.) |
| Contrast Ratio | 1000:1 |
| Response Time | MPRT 1 ms |
| Lifespan | 30,000 hrs |
| Operation Hours | 7 × 16 H |
| Surface Treatment | Haze 25%,3H |
| Flicker-free Technology | Yes |
| Low Blue Light | Hardware blue light protection |
| Function | |
| HDR | HDR 10 |
| Device Ports | |
| Input Port | 2 × HDMI 2.1 (3840 × 2160@144 Hz & 1920 × 1080@288 Hz), 2 × DP 1.4 (3840 × 2160@160 Hz & 1920 × 1080@320 Hz) |
| Output Port | 1 × Audio out |
| Power & Environmental Conditions | |
| Power Supply | 12 VDC, 4 A |
| Power Type | power adapter |
| Power Consumption | 26 W (basic), 38 W (typ.), 40 W (max) |
| Standby Power Consumption | <0.5 W |
| Operating Temperature | 0 °C to +40 °C (+32 °F to +104 °F) |
| Operating Humidity | 10% – 85% (RH) |
| Storage Temperature | -20 °C to +60 °C (-4 °F to +140 °F) |
| Storage Humidity | 5% – 90% (RH) |
| General | |
| Inclined Angle | -5° / +15° |
| Left and Right Rotation Angle | -20° / +20° |
| Vertical Rotation Angle | +90° |
| Height Adjustment | 110 mm (4.33″) |
| Product Dimensions | 613.8 mm × 362.5 mm × 70.7 mm (24.17″ × 14.27″ × 2.78″) (W × H × D), without wall-mount bracket |
| Package Size | 704 mm × 505 mm × 159 mm (27.72″ × 19.88″ × 6.26″) (W × H × D) |
| Frame Width | U/L/R/D: 2.2 mm/2.2 mm/2.2 mm/17.4 mm(0.09″ / 0.09″ / 0.09″ / 0.69″) |
| Net Weight | 5.6 kg (12.35 lb) |
| Gross Weight | 7.4 kg (16.31 lb) |
| Casing Color | Black |
| Control Mode | Joystick |
| Status Indicator Light | Yes |
| Wall Mount VESA | 100 mm × 100 mm (3.94″ × 3.94″) |
| Accessory | Power Adapter, Bracket, Base, DP Cable, User Manual (QR Code), Legal and Regulatory Information, Energy Label |
| Optional Accessory | Wall mount |
| Certification | |
| Certifications | CE EMC, CE LVD, CE ERP |
