| TS-832PX-4G | |
| Download Datasheet | https://www.qnap.com/th-th/product/ts-832px/specs/hardware/TS-832PX-4G.pdf |
| CPU | AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz processor |
| CPU Architecture | 64-bit ARM |
| Floating Point Unit | Yes |
| Encryption Engine | Yes |
| System Memory | 4 GB SODIMM DDR4(1 x 4 GB) |
| Maximum Memory | 16 GB (1 x 16 GB) |
| Memory Slot | 1 x SODIMM DDR4 |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Drive Bay | 8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: |
| 3.5-inch SATA hard disk drives | |
| 2.5-inch SATA hard disk drives | |
| 2.5-inch SATA solid state drives | |
| Hot-swappable | Yes (Not supported M.2 SSD) |
| M.2 Slot | Optional via a PCIe adapter |
| SSD Cache Acceleration Support | |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ |
| Wake on LAN (WOL) |
Only the 2.5GbE port |
| Jumbo Frame | Yes |
| PCIe Slot | 1 |
| Slot 1: PCIe Gen 2 x2 | |
| PCIe bandwidth limitations will restrict the NAS 10GbE performance. | |
| Card dimensions for PCIe slot:210 x 68.9x 24.76 mm / 8.27 x 2.71 x 0.97 inches. | |
| USB 3.2 Gen 1 port | 3 |
| Form Factor | Tower |
| LED Indicators | System Status, LAN, USB, HDD1~8 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 180.2 × 329.3 × 280.8 mm |
| Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) | |
| Weight (Net) | 7.05 kg |
| Weight (Gross) | 8 kg |
| Operating Temperature | 0 – 40 °C (32°F – 104°F) |
| Storage Temperature | -20 – 70°C (-4°F – 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 250W, 100-240V AC, 50/60Hz, 3.5A |
| Power Consumption: Disk Standby Mode | 27.949 |
| Power Consumption: Operating Mode, Typical | 50.858 W |
| Tested with drives fully populated. | |
| Fan | System fan: 2 x 120mm, 12VDC |
| CPU fan: 1 x 60mm | |
| System Warning | Voice prompts or Buzzer |
| Kensington Security Slot | Yes |
| Warranty | 2 Years |
| Max. Number of Concurrent Connections (CIFS) – with Max. Memory | 700 |
